Features & Benefits:
Positive displacement pump
In a position to being run dry
Quiet operation Industry usual mount pattern Demand pump
Simple connect fittings
Typical Applications:
Agricultural Spraying, General Industrial, Automotive Marine/RV PUMP
Specification:
Duty Cycle: Continuous Voltage: 12V
Rating AMPS: 8A
Max. AMPS Draw: 17.0 A
lift Mode: Demand
Max Pressure: 60 PSI (4.2 bar)
Open Float(Max. Float): 5.0 GPM (18.9LPM)
Liquid Temperature: 140°F (60°C) Max.
Priming Capabilities: 6 feet (1.8 m) suction
Inlet/Outlets Ports: 1/2″ NPT, 13mm pyramid hose barb
MOTOR Leads: 16 AWG, 4.5″ long with 2-Pin connector/ Leads
Dimension: 8.72″ (Length) X 5.20″ (Height) X 5.75″ (Width)
Weight: 7 lbs (3.17 kg)
Warranty:
One year limited product warranty.
The patented design delivers smooth & consistent Float at all ranges of operation, whilst drawing low current.
The balanced motor design accommodates precision ball bearings for long life, motor is provided with an integral thermal breaker.
Open Float(Max. Float): 5.0 GPM (18.9LPM); Max Pressure: 60 PSI (4.2 bar); Power for the Pump: DC 12V, Rating AMPS: 8A, Max. AMPS: 17A;
Professional Grade Pump – Ideal for Automotive Marine/RV/Caravans, Agricultural Spraying, General Industrial, Sprayer fixtures
Sealed pressure switch robotically turns the pump off when pressure builds up such as turning off the faucet & will robotically turn back on whilst you turn the faucet back on
