The Seaflo 36 series pumps get rid of rapid switch cycling completely. Matched with a sealed
motor, heavier wire & low amp draw, the 36 series is designed to tackle any task from
constant waft at high pressure to the abusive enviornmet of off and on spot spraying within the field.
Typical Applications
Water Remedy/Ro
Beverage/Food Service
Distillation Equipment
Agricultural Spraying
General Industrial
Automotive
Marine/RV
PUMP
Type:3 chamber positive displacement diaphragm
pump, self priming, able to being run dry
Mode:By pass
Max Really helpful Temperature :140°F (60°C) Max.
Priming Capabilities :6 feet (1.8 m) suction lift
Max Pressure:120PSI (8.3 bar)
Inlet/Outlet Ports:3/8″-18 FNPT
Weight:5.2 lbs (2.35 kg)
MOTOR
Duty Cycle: Continuous
Leads
DC: 16 AWG, 4.5″ long with 2-Pin connector/Leads
Voltage:DC 12v
Positive displacement pump; Can run dry
Quiet operation; Demand Pump
Simple connect fittings; Industry usual mount pattern
2.0 gallons per minute (7.5 liters per minute)
120 PSI pressure (8.3 BAR); 10.0A Max
