*Ultra-thin ultra-small (16.5 × 17mm).
*Good harmonics too easy to FCC / CE certification.
*The penetration ability (measured through 8 floors).
*The use of the up to date version of the U.S. SI4432 IC, stable performance.
Features: *Frequency range: 470mhz.
*Sensitivity as much as-121dBm.
*Maximum output power: 20dBm.
*Ddata transfer rate:0.123-256kbps.
*FSK, GFSK and OOK modulation.
*Power supply: 1.8-3.6 V.
*Ultra-low-consumption shutdown mode.
*Digital received signal strength indication (RSSI).
*Wake time.
*Automatic matching and two-way antenna switch Keep watch over.
*Configurable packet structure.
*Preamble detection.
*64-byte send and receive data register (FIFO).
*Low power detection.
*8-bit ADC and temperature sensor.
*Operating temperature range: -40 ~ +80°C.
*Integrated voltage regulator.
*Frequency hopping.
*Power-on reset function.
*Built-in lens adjustment .
Applications: *Remote Keep watch over.
*Remote meter reading.
*Home security alarm and remote keyless entry.
*Industrial Keep watch over.
*Telemetry Home Automation.
*Personal data records.
*Toy Keep watch over.
*Sensor networks.
*Tire pressure monitoring.
*Health Monitoring.
*Wireless PC peripherals.
*Tag readers .
Feedback:
We greatly appreciate your POSITIVE feedback. Please do NOT leave negative feedback without asking for assist. Our team is to offer Top Level Customer Service, so we will be able to try our absolute best to resolve any problem.Thanks very much!
Frequency range: 470mhz.
Sensitivity as much as-121dBm.
Maximum output power: 20dBm.
Ddata transfer rate:0.123-256kbps.
FSK, GFSK and OOK modulation.
