Product Description
The output of the electric fishing machine is impulse current with a view to effectively stimulate the brain of the fish but protected for human.The output of electrofisher anode connected with net and cathode connected with wire which put in water;Plug in the hand or foot switch which we can provide with the electrofisher;Connect the electrofisher to batter(12V or 24V),anode to anode and cathode to cathode; Pressing electrofisher switch and than it can work(you’ll adjust the output power by the digital indicators on the electrofisher).That may be all of the simple process for how to electrofish.
Technical Data
Input Voltage:12 VDC Nominal Range ( 9.8-14V/DC)
Input Current:10-120Amps
Output Voltage:Pulse 1000V/AC
Output Power:8200 watts maximum (in peak) ( operating 1400-1600 watts)
Pulse Width:1%-15% adjustable
Output Frequency:20-120HZ adjustable
Output Waveform:sine wave
Weight:< 2 kg
Dimensions:180*140*70((MM)
Battery:12 V DC (any model)
Battery Life:27Ah (2-3 hours of electrofishing),Larger battery-longer fishing.
Overload Protection:Yes (120A)
Low Voltage Protection:Yes (Less than 9.2V/DC protection )
High Voltage Protection:Yes (Exceed 15V/DC protection )
Over-temperature Protection:85ºC
Short-circuit Protection:Output short circuit protection
Reverse Polarity Protection:Input reverse protection
Waterproof Protection:Machine or switch contact water protection
NOTE:
we can send the product to you as soon as conceivable
When you have any questions , please feel free to contact us
With advanced digital technology
Adopts unique structure of the secondary output
Duty cycle and frequency are adjustable independently of one another
With hard short circuit protection, effective protection of the life of the machine
Uses professional fishing device designed computer program algorithm
